400W LED Commercial Grade 150lm/w IP40 Flat Linear 110-277VAC High Bay SFLHB400WL5H

1 of 5

* Images are for reference only

Manufacturer
SJ
Manufacturer Part Number
PHB12-400NN-CCL15K
Part Number
FLHB400WL5H
HS Code
8539.52.0091
Weight
30 lbs
PHB12-400NN-CCL15K LED 400W Commercial Grade Flat Linear High bay. Ideal replacement for traditional high bay with over 80% energy saving. Superior replacement for traditional florescent and halide high bay fixtures.

Product Specifications

Fixture Type
Flat High Bay
Fixture Series
PHB
Wattage
400W
Lumens
60,000
Lumen/Watt
150:1
HID Equivalent
1500
Lighting Color
5000K
Voltage
110-277VAC
Hertz
60/50
CCT Selectable
No
Use Rating
Continuous
Power Factor %
>0.90
THD %
<20%
Surge Suppression
3kV
Environment
Indoor
IP Rating
IP40
NEMA Rating
Damp Location
Beam Angle (deg*)
120
Beam Angle Type
5 Medium Wide
CRI/Ra
80
Dimmable
0-10V
LED's
SMD2835
Min Temp Range
-30°C = -22°F
Max Temp Range
40°C = 104°F
UL Certified
Yes
DLC Eff. Rating
Premium
Fixture Material
Aluminum
Fixture Color
White
Optical Lens
Polymethylmethacrylate (PMMA)
Mounting
Chain Standard
Min. Rated Life (hr)
50,000
Warranty
5 Year
Manufactured Origin
Non-USA
FCC Certification
Yes
ETL Certified
None
Fixture Type
Flat High Bay
Fixture Series
PHB
Wattage
400W
Lumens
60,000
Lumen/Watt
150:1
HID Equivalent
1500
Lighting Color
5000K
Voltage
110-277VAC
Hertz
60/50
CCT Selectable
No
Use Rating
Continuous
Power Factor %
>0.90
THD %
<20%
Surge Suppression
3kV
Environment
Indoor
IP Rating
IP40
NEMA Rating
Damp Location
Beam Angle (deg*)
120
Beam Angle Type
5 Medium Wide
CRI/Ra
80
Dimmable
0-10V
LED's
SMD2835
Min Temp Range
-30°C = -22°F
Max Temp Range
40°C = 104°F
UL Certified
Yes
DLC Eff. Rating
Premium
Fixture Material
Aluminum
Fixture Color
White
Optical Lens
Polymethylmethacrylate (PMMA)
Mounting
Chain Standard
Min. Rated Life (hr)
50,000
Warranty
5 Year
Manufactured Origin
Non-USA
FCC Certification
Yes
ETL Certified
None
MSRP:
$N/A
Your Price:
N/A

Commercial Grade Flat Linear High Bay Fixture. Our best manufactured fixture so far and is our #1 customer's choice. Designed for Indoor use including warehouse, manufacturing, garages, storage and many other areas with 12-18 feet ceiling height.

Features:

  • Flicker Free
  • Durable High Quality Construction
  • Easy installation
  • Averaging 80% energy savings with matched lumens
  • UL/cul Listed
  • Dimensions 47.5" Long x 16" Wide x 2.5" High
